This service manual is for New Holland Workmaster 35, Workmaster 40 Tier 4B (final) Tractor. It includes service, repair, removal, installation, disassembly, assembly, troubleshooting and other required information. This manual will make your repair work smoother and easier. You will realize that this is a very valuable manual.
Part number 48144024
1st edition English
June 2017
Manual Type: Service Manual
Total Pages: 1595
Models Covered:
Workmaster 35
Workmaster 40
Tier 4B (final)
Compact Tractor
New Holland Tractor
Workmaster 35 ROPS – From PIN LSM0W35Rxx0010001 to LSM0W35RHH0010200
Workmaster 40 ROPS – From PIN LSM0W40Rxx0010001 to LSM0W40RKH0010198
Manual Contents:
INTRODUCTION
Engine – 10
Clutch – 18
Power coupling – 19
Transmission – 21
Four-Wheel Drive (4WD) system – 23
Front axle system – 25
Rear axle system – 27
Hydrostatic drive – 29
Power Take-Off (PTO) – 31
Brakes and controls – 33
Hydraulic systems – 35
Hitches, drawbars, and implement couplings – 37
Steering – 41
Wheels – 44
Electrical systems – 55
Platform, cab, bodywork, and decals – 90
SPECIAL TOOL INDEX
ELECTRICAL SCHEMATIC – ROPS – 48090750
After the payment is completed, you will go directly to the download page, and you will also receive an email with a download link. If you cannot receive the email in time, please check the spam email.
File Format: PDF
Compatible: All Versions of Windows & Mac
Delivery: Instant Download
Language: English
Requirements: Adobe PDF Reader
